Allgemein
Host-Konnektivität
2.5 Gigabit Ethernet / 10 Gigabit Ethernet
Gehäusetyp
Rack - einbaufähig - 2U
Gesamtspeicherkapazität
0 GB
Anzahl installierter Peripheriegeräte/Module
0 (installiert) / 12 (Max)
Integrierte Peripheriegeräte
LED Panel, 3 x 60 mm Lüfter, Summer
Prozessor / Arbeitsspeicher
Installierte Prozessoren
1 x AMD
Max. unterstützte Anzahl
1
Max. Turbo-Taktfrequenz
5.1 GHz
RAM
16 GB (installiert) / 128 GB (unterstützt) - DDR5
Installierter Flash-Speicher
5 GB
Massenspeicher-Controller
Schnittstellentyp
SATA 6Gb/s
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, JBOD
Netzwerk
Data Link Protocol
10GbE, 5GbE, 2.5GbE, 100Mb LAN, 1GbE
Netzwerk/Transportprotokoll
IPv4, IPv6, PPTP, L2TP, OpenVPN, WireGuard, QBelt, QuFTP
Remoteverwaltungsprotokoll
SNMP 2, SNMP 3, SFTP, TFTP, SSH, Telnet, HTTP, HTTPS
Kompatibilität mit Netzwerk-Services
Apple File Protocol (AFP), FTP, Server Message Block (SMB), Microsoft CIFS, Network File System v3 (NFS v3), Network File System v4 (NFS v4), Web-based Distributed Authoring and Versioning (WebDAV), FTPS
Leistung
Gleichzeitige Verbindungen (CIFS): 5000 - (mit max. Speicher)
Maximale Poolgröße: 308 TB
Maximale Anzahl von Speicherpools: 128
Maximale Volumengröße: 250 TB
Maximale Anzahl von Volumen: 128
Maximalgröße des gemeinsamen Ordners: 250 TB
Max. Anzahl geteilter Ordner: 512
Max. LUN-Größe: 250 TB
Max. FTP-Verbindungen: 1024
Min. Snapshot-Intervall: 5 min
Max. FTP-Verbindungen: 1024
Lokales Nutzerkonto: 4096
Lokales Gruppenkonto: 512
Domain-User/Gruppenkonto: 200000
Systemprotokoll & Mitteilungszentrale: 3000 Ereignisse pro Sekunde
Virtuelle Hosts: 32
Leistungsmerkmale
Gleitkomma-Einheit, Encryption Engine, eingebaute Hardware-Transcodierung, GPU-Passthrough, Wake on LAN (WOL), Jumbo-Frames-Support, Storage Pool, SED Storage Pool, JBOD Expansion, VJBOD Cloud, iSCSI Service, Fibre Channel Service, file-based iSCSI LUN, block-based iSCSI LUN, LUN Mapping, LUN Masking, WWPN Aliases Import/Export, FC Port Group, FC Port Binding, multipath IO (MPIO), Online LUN-Kapazitätserweiterung, LUN snapshot, Auto Tiering, RAID Group, RAID Level Migration, RAID Expansion, Storage Pool Expansion, RAID Hot Spare, RAID Sync/Rebuild/Scrubbing, EXT4-Dateisystem, Disk, Enclosure Locate, Disk S.M.A.R.T. Scan, Disk S.M.A.R.T. Data Migration, Secure Erase, SSD-Verkleidung, SSD life estimation, Disk Roaming, Disk Standby, Volume Snapshot, Snapshot Retention Policy, Self-serve Snapshot Recovery, Application Consisted Snapshot, Snapshot Full Clone, Snapshot Replica / Vault, SSD read-only Cache, SSD read-write cache, SSD write-only cache, SSD Cache RAID, SSD Profiling-Tool, Verwaltung externer Geräte, Mount Smart Phone (MTP), Dateistation, Object Storage, FTP-Server, domain security, Domain Controller, Windows ACL, Resource Monitor, Smart Fan, Plan ein/aus, Virtual Switch, Anschluss-Bündelung, VLAN-Unterstützung, DHCP-Server, security counselor, malware remover, 2-step verification, Allow/Deny List, Access Protection, Service-Zusammenfassung, firewall, Windows ODX, Qsync, HybridMount, Hybrid-Backup-Synchronisierung, Hyper Data Protector, Boxafe, Qsirch, QuMagie, Virenschutz-Analyse, QVPN Service, HD Station, LDAP server, SQL Server, Qfiling, Media Streaming Add-on, QmailAgent, QuWAN, DA Driver Analyzer, RADIUS-Unterstützung, Reset-Taste, FXP-Unterstützung
Verschlüsselungsalgorithmus
AES-NI, FIPS 140-2, 256-Bit-AES, TLS 1.0, TLS 1.1, TLS 1.2, TLS 1.3
Erweiterung/Konnektivität
Erweiterungseinschübe
12 (gesamt)/ 12 (frei) x Hot-Swap - 2.5" / 3.5" (6.4 cm / 8.9 cm)
Erweiterungssteckplätze
2 (gesamt)/ 2 (frei) x M.2 2280
3 (gesamt)/ 3 (frei) x PCI Express 4.0 x4
Schnittstellen
2 x Ethernet 1000Base-T - RJ-45
2 x 2.5 Gigabit Ethernet
2 x USB 3.2 Gen 2 - Type A
Verschiedenes
Enthaltene Kabel
1 x Netzwerkkabel
Mitgeliefertes Zubehör
48 x Senkkopfschrauben (für 3,5" (HDD)), 36 x Senkkopfschrauben (für 2,5" (HDD)), 2 Netzkabel
Stromversorgung
Stromversorgungsgerät
Internes Netzteil
Max. unterstützte Anzahl
2
Erforderliche Netzspannung
Wechselstrom 100-240 V
Gestellte Leistung
550 Watt
Software / Systemanforderungen
Speicherbetriebssystem
QNAP QuTS hero h5.1.3 / QTS 5.1.3
Software inbegriffen
IronWolf Health Management
Erforderliches Betriebssystem
Apple macOS 10.10 oder später, Ubuntu 14.04, CentOS 7.0, Red Hat Enterprise Linux 6.6, SuSE Linux 12 oder höher, IBM AIX 7, Oracle Solaris 10 oder später, Microsoft Windows 7 / 8 / 10 / 11, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2022
Herstellergarantie
Service und Support
Begrenzte Garantie - 5 Jahre
Abmessungen & Gewicht (Transport)
Umgebungsbedingungen
Min Betriebstemperatur
0 °C
Max. Betriebstemperatur
40 °C
Zulässige Luftfeuchtigkeit im Betrieb
5 - 95% RH (non-condensing)
