This new and original packaging Dell P0H48 motherboard is designed for use in Optiplex 580 Tower PC . It is particularly suitable for the replacement and repair, as it is sent without additional accessories and all other components should be adopted ideally.
Additional Hardware for the Dell P0H48 motherboard You naturally also available from us, you should plan a simultaneous upgrade of the Optiplex 580 . As a processor, you can for example here an AMD Athlon, Sempron and AMD Phenom II use. Thus, you can choose directly on the required performance. The maximum memory capacity is 16 GB, which thus enables very powerful systems.
For more peripheral and communication are an Ethernet port, eight USB and two audio ports. The integrated graphics ATI Radeon HD 4200 of the Dell P0H48 motherboard can be used via the DisplayPort. For quick connection of external hard drives also an eSATA port is available.
Use the Dell P0H48 motherboard whether to upgrade or repair your system, you can start from the usual Dell quality. Check the compatibility case easiest with the manufacturer's information, such as the Service Manual.
||POH48 Dell Motherboard - Motherboard for Dell Optiplex 580 Tower
||Motherboard - Mainboard
||AMD Phenom II Quad Core
AMD Phenom II Triple Core
AMD Phenom II Dual Core
AMD Athlon quad-core AMD Athlon Triple Core
AMD Athlon Dual Core
AMD Sempron single core >
||4x 240-pin DDR3 DIMM slots
||DDR3 Non-ECC SDRAM , 1066MHz ,
||Integrated ATI Radeon HD 4200 Graphics1
||2x PCI slot
1x PCI Express x4 slot
1x PCI Express x16 slot
|Audio RealTek ALC269 High Definition Audio
||1x RJ45 Ethernet / LAN Port
8x USB 2.0 (includes two internal on MT, DT and SFF)
2x back panel audio connectors
1x eSata connector
1x Rear Display Port
||Optiplex 580 Tower
||1x motherboard, other accessories not included
